Sonic accuracy and durability are the most important features of a professional power amplifier, which have been considered in all elements of the MP2800. Each model in the MP Series uses an all all-steel chassis along with state of the art electronic components, all housed within a unique amplifier design that provides high power and clean signal reproduction in a variety of applications and loudspeaker configurations.
New FRT Circuitry
With a high slew rate across the MP Series, each amp reacts quickly to drive your loudspeakers as clearly and accurately as possible. Newly developed FRT or ‘fast reaction technology’ in the ‘s’ models create an even faster low frequency response assuring the MP2800 does not miss a beat during performance.
Stereo & Bridge efficiency
The MP2800 will work efficiently in stereo and bridge modes. The amplifiers also run down to 2 Ohms safely in stereo mode which means that the amplifiers can be used for a multitude of setups. Use in bridge mode with an individual high-powered subwoofer or use a single MP2800 to power multiple speakers equally.
Features
• High-end power amps with optional bridged mono operation mode
• Built in toroidal transformer
• Rear panel ground lift switch
• Class H Topology
• All steel construction
• Continuously variable speed fan
• Sophisticated protection circuitry including; Soft start protection relay; Thermal overload protection; Short circuit protection; Open circuit protection
• Front controls including: Power Switch, Channel A and Channel B gain controls
• Front panel LED indicators for Power On, Peak, Protect
• Stereo/Bridge Mode switch on rear of unit
Specifications
MP 2800
Power: Per Channel (1% THD)
Stereo Mode 8 Ohms
600 Watts
Stereo Mode 4 Ohms
950 Watts
Stereo Mode 2 Ohms
1450 Watts
Bridged Mono Mode 8 Ohms
1700 Watts
Bridged Mono Mode 4 Ohms
2700 Watts
Input Sensitivity & Impedance
At 4 Ohms
0.775v
Unbalanced 1/4″ Jack
10K Ohms
Balanced XLR
20K Ohms
Voltage Gain
36dB
Slew Rate: 8 ohms FULL SWING
Stereo
>40v/u sec
Channel Seperation
76dB
Signal to Noise (20Hz – 20kHz)
100dB
Distortion (SMPTE-1M)
less than 0.05%
Frequency Response
+/-1dB @ 4 Ohms
20Hz to 20kHz
+/-3dB @ 4 Ohms
5Hz to 50kHz
Damping Factor (8 ohms, 1kHz)
Greater than 400
Topology
Class H
Connectors
Input
XLR & 1/4″ TRS
Output
5 Way Binding Posts & Speakon or Speakon
Controls
Front
AC Switch, CH1 & CH2 Gain Knobs
Rear
Stereo/Bridge Mode Switch
Indicators
Power switch on/off mute, Short circuit, Open circuit, Thermal
Cooling
Variable Speed Fan
Gross Weight (kg / lbs)
29.5kg / 65lbs
Net Weight (kg / lbs)
28kg / 61.6lbs
Dimensions (HxWxD) mm
133 x 483 x 355
Dimensions (HxWxD) inches
5.2 x 19 x 13.9
* Appearance and specifications of this product are subject to change without notice.
