The AT2010 is designed to bring the studio-quality articulation and intelligibility of Audio-Technica’s renowned 20 Series to the stage, for crystal-clear vocal performances. Featuring the same 16 mm low-mass diaphragm found in the critically acclaimed AT2020 side-address studio condenser, the AT2010 excels wherever articulate vocals are needed: in houses of worship, for solo performances, jazz vocalists, singer/songwriters, and more.
FEATURES
Extended frequency response and superior transient response for smooth, natural sonic characteristics
High SPL-handling and wide dynamic range provide unmatched versatility
Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
Multi-stage grille design offers excellent protection against plosives and sibilance without compromising high-frequency clarity
Corrosion-resistant contacts from gold-plated XLRM-type connector
Rugged, all-metal and construction for years of trouble-free service
Quiet-Flex™ stand clamp provides silent, flexible microphone positioning
Weight
0.52 kg
Dimensions
24.64 × 13.21 × 7.49 cm
ELEMENT:
Fixed-charge back plate, permanently polarized condenser
POLAR PATTERN:
Cardioid
FREQUENCY RESPONSE:
40-20,000 Hz
OPEN CIRCUIT SENSITIVITY:
–48 dB (3.9 mV) re 1V at 1 Pa
IMPEDANCE:
100 ohms
MAXIMUM INPUT POWER:
136 dB SPL, 1 kHz at 1% T.H.D.
DYNAMIC RANGE (TYPICAL):
113 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO:
71 dB, 1 kHz at 1 Pa
PHANTOM POWER REQUIREMENTS:
48V DC, 2 mA typical
OUTPUT CONNECTOR:
Integral 3-pin XLRM-type
ACCESSORIES INCLUDED:
AT8470 Quiet-Flex stand clamp for 5/8″-27 threaded stands; 5/8″-27 to 3/8″-16 threaded adapter; soft protective pouch
AUDIO-TECHNICA CASE STYLE:
T7
Reviews
There are no reviews yet.
Be the first to review “Audio Technica AT2010”Cancel Reply
The CM20P features flexible top and bottom sections for a variety of positioning applications. The condenser element and cardioid pickup pattern provide optimal sound quality for all types of speech and vocal presentations.
